Digital ELCB with volt and amp miter with high low voltage protection overload protection

shock protection short circuit protection, fault indication provided adjustable leakage current with 0.1 amp accuracy

 1799

MRP 4500
You save 2701 (60.02%)


Type: ELR Panel (ELCB)

Sub Type: Single Phase,Digital

Weight: 1.5 KG

Manufacturer: Mivan Technologies

Tax: 18 %

In Stock

Delivery in 2-4 days in major cities and 3-7 days in remote area.
Worldwide delivery available.


100% Secure Payments, 7 Days Easy Return Policy.

Item Specifications :

Condition : A brand new unused, undamaged item that is fully operational and functions as intended.

Warranty : 1 Year Manufacturer.

Warranty Service : Repair or Replacement.



Package Contain :

1 ELCB

1 Test report.



Product Descriptions :

Microcontroller based Digital ELCB with display of voltage and ampere,

Display leakage current from 0.7 to 30 mA with 0.1 mA accuracy

Auto start when fault resolved no need to reset

Adjustable Overload from 2A to 32 A

Adjustable leakage current 3mA to 50mA

If trip through shock then auto reset in 1 min if trip 2 times due to sock then it lock and user need to reset

Spike protection if trip due to spike reset in 7 minute.

Surge protection

This Model Will Automatically Switch off Your Main Supply during Any Overload, high & low voltage & Short Circuit Condition.

This is fully automatic, so if fault is resolved then it automatically turns on output supply.

It has electric shock Protection (in case of any person touch live wire by mistake then our ELCB close main supply instantly and save their life)

High & Low Voltage Protections. High voltage cutoff 280 VAC. Low voltage cut off 150 VAC.

Overload Protections. Adjustable overload up to 32 A

Protection against short circuits.

shock protection.

Over current protections.

Adjustable Leakage Currant 3mA to 50mA.

Test button provided to test ELCB. When you press test button ELCB trip immediately. Reset button provided to Reset ELCB.

High quality ISI Marked 32 A MCB provided.

High and Low Voltage indication,

trip indication,

Power indication,

Leakage current indication provided

Earth protection provided

working and bypass indication provided

Emergency bypass indication provided.

Auto and Bypass switch available. If you put it in auto mode then elcb automatically turns on if fault is resolved. (for ex if elcb trip due to high/low voltage, then elcb trip immediately but when voltage resolved, it will automatically turn on and give supply at output )

Bypass mode is provided : If ELCB trips during any fault in the supply line and even after the user wants to start their appliances then the user can operate in bypass mode.

Overloading protection given by MCB so if it trip due to overloading then it will not start automatic but user need to switch on MCB

It cut both Phase and neutral supply during fault.

Main advantage of this ELCB is, it does not require earthing. Earthing requires only because of metal body, no use of earthing in circuit.
