ODT HD ON Delay digital timer for single phase appliances and motor with HV LV OL and DRY protection

with battery backup user can set from 1 second to 999 minutes

 1320

MRP 5200
You save 3880 (74.62%)


Type: Heavy Duty series 2 years warranty

Sub Type: Digital Timer 1 Phase

Weight: 0.5 KG

Manufacturer: Mivan Technologies

Tax: 18 %

In Stock

Delivery in 2-4 days in major cities and 3-7 days in remote area.
Worldwide delivery available.


100% Secure Payments, 7 Days Easy Return Policy.

Item Specifications :

Condition : A brand new unused, undamaged item that is fully operational and functions as intended.

Warranty : 2 Year Manufacturer.

Warranty Service : Repair or Replacement.



Package Contain :

1 Digital Time Switch

1 user manual with technical details.

1 Warranty card of 2 years warranty

4 Screw and Hole plugs

1 Drill template



Product Descriptions :

Programmable ON DELAY Digital Timer, It will start connected appliances after preset time

(for example you have set 5 minute for ON Delay time. then press the start button, motor or any connected appliances will start after 5 minute (preset time)).

Battery-backup for 500 hrs. in case of power failure. No need of restart unit after resumption of power supply. Even after resumption of power supply, unit will work as per programmed only.

High & Low Voltage protection,

Adjustable voltage limit (High and low both voltage protection limit adjustable)

Short circuit protection



Current based dry run protection,

Adjustable dry run current from 0 to 30 A



Over load Protection,

Adjustable overload from 0 to 30 A



Two seperate display for volt and amp.

protection bypass facility

Input Voltage : 230 VAC

Output Voltage : 230 VAC

High accuracy in over load and dry run current

Start and stop button provided to start and stop motor

Set button provided to set the current voltage and timer.

Reset button provided to reset the unit

Factory reset facility in case of incorrect value entered.

Be free from data lost problem, As all programmed data will be stored in memory.

40 A Relay provided.

Auto & Bypass facility provided.

Supply Voltage 220-270 VAC. Microcontroller based,

Best Quality Guaranteed. Used For Automatic Switching On/Off For single phase Motor upto 5 HP / A.C / Heater / cold storage / Electronic Sirens / Street Light / Signage Board / Hydroponics / Signalling / Home Automation
